Primary Standard Calibration




Contact Us:
(818) 701-4969

Micro Quality Calibration ("MQC") is at the forefront of the Metrology industry with a primary standard calibration service offering and capabilities unmatched among its peers. Our A2LA ISO/IEC 17025-2005 accreditation mandates us to uphold the highest level of quality assurance, documentation, and accuracy so that you can rest assured your equipment will be serviced to the highest quality disciplines while our staff provides exceptional service and keeps you updated on your equipment.

Our Primary Standard Laboratory boasts the most accurate precision measurement test equipment to meet or exceed the most demanding uncertainty requirements bestowed on us by our customers. All primary standard calibrations are performed in our environmentally controlled climate (both temperature and humidity are closely monitored 68°F with relative humidity not to exceed 40%) to give the lowest degree of measurement uncertainty. Request a price quote today!



We utilize Primary Standards traceable to one or more of the following:

  • Direct accredited calibration to National Bureau Standards
  • Direct Traceability to N.I.S.T.
  • OEM accredited calibration



Preparation

Preparation of your precision measurement test equipment is just as important as the calibration. Preparation varies and is equipment specific. Any test instrumentation is thoroughly cleaned and inspected and allowed typically 24 to 72 hours to stabilize the temperature of the gage. This is done to obtain the most accurate measurement. When the gages are calibrated they are demagnetized and inspected for nicks, burrs, corrosion, and any other damage that may hamper accuracy and repeatability. Once calibrated, they are certified (with data) and oiled and packaged ready to be shipped to the customer.

Should your precision measurement test equipment be damaged or out of tolerance weoffer replacements. Please inquire with one of our service representatives for more information.

Capabilities

  • Metric Standards with a range of 0mm - 500mm at +/-2ppm
  • English Standards with a range of 0” - 20” at +/-1ppm
  • Optical Flats up to 8” with an accuracy of +/-2ppm
  • Gage Block Comparator with a range of 0” - 20” at +/-2ppm
  • ID/OD Comparators with an accuracy of +/-2ppm



Capabilities / Accuracy

Equipment Type Range Accuracy

Cylindrical Plugs 0" - 10" Diameter  +/- 2ppm
Cylindrical Rings 0" - 10" Diameter  +/- 2ppm
Gage Block Comparator 0" - 20"  +/- 2ppm
I.D. & O.D. Comparator 0" - 17" I.D. / 0" - 20" O.D.   +/- 2ppm
Gage Blocks Metric 0mm - 500mm  +/- 2ppm
Gage Blocks English 0" - 20"  +/- 1ppm
Gage Blocks Angle Multi .25 sec
Inspection Balls Up to 4"  +/- 2ppm
Optical Flats Up to 10"  +/- 2ppm
Thread Wires 4 - 80 TPI  20ppm
Wire Acme Multi  20ppm
Gear Wire Multi  20ppm
* If not on the list, please inquire *



Certification

Each calibration / repair / new equipment sale / used equipment sale comes with certificate traceable to N.I.S.T and includes:

  • Barcode & Instrument I.D.
  • Full Data (Before / After) Calibration and/or Repair
  • Condition Received / Condition Returned / Reason for Service
  • Description of Item incl. Model & Serial No.
  • Measuring Range
  • Procedure Used
  • Calibrating Tech
  • Temperature & Humidity
  • Accuracy
  • Calibration Standards Employed
  • Numbers Traceable to N.I.S.T.
  • Dual Signatures (Tech and Approval  Signature)
  • Certificate Number
  • Purchase Order
  • Calibration Date  / Next Cal Date
  • Recall / Cycle
  • Repair / Adjustment Note (when applicable)
  • A2LA Accreditation Logo (upon request)
  • Uncertainty (upon request)

Whether you have Primary Standards, Secondary Standards or Working Standards, MQC is one of the few Metrology Laboratories that has the ability to calibrate your precision measurement test equipment in each of its service line disciplines.Turnaround time is 5 business days with expedite service available.

On-site Calibration Services Available

  • Minimal down time lets you focus on maximizing value
  • Convenient
  • No shipping of delicate and costly instruments
  • Increase productivity
  • Expedite on-site service available



Proprietary Calibration Software Gives our Customers 24/7 Access

  • 24/7 Access to Certificates
  • 24/7 Access to Equipment Lists
  • 24/7 Access to Recall Reports
  • 24/7 Access to Calibration Data on your Equipment

MQC can not only help its customers create an accurate comprehensive recall list but also notifies its customers monthly on equipment past due, equipment due in the next 30 days and equipment due the following month to put you in complete control to better manage your precision measurement test equipment, ensure 100% conformity and minimize costly downtime. All this information is also available at your fingertips by simply accessing our web portal and entering your customer number and password.

Why Micro Quality Calibration?

  • Accredited to the highest standards
  • Leading State-of-the-art equipment
  • Environmentally controlled multi-laboratory facility
  • In-house and onsite calibration services available
  • Proprietary calibration software gives customers 24/7 access to certificates, equipment lists, recall reports, calibration data, and more
  • Each calibration / repair comes with certificate traceable to N.I.S.T, calibration data, standards used, and barcode for inventory tracking
  • Ability to repair any instrument we calibrate to the component level and certify to Manufacturer, Federal, Military and Industrial specifications
  • No subcontracting to 3rd parties
  • OEM Trained Technicians
  • Fast 5 business day turnaround time (expedite services available)
  • Free pick-up and delivery with shipments of seven (7) items or more (regionally)
  • Rest assured your valuable precision measurement test equipment will be packaged, picked-up, delivered, and shipped with care
  • Global shipping
  • Sales of over 160 lines of new / used precision measurement equipment (sale items are calibrated at no charge)
  • Ability to calibrate Primary, Secondary and Working Standards in each category
  • Technical Support Available
  • Small Women Owned Business (matches both Federal and by State Guidelines)

When Quality and Precision Matter we are the only choice.

We represent over 160 lines of precision measurement equipment. Don’t forget to ask us about our used precision measurement test equipment product offering. Below is a listing of just some of our of precision measurement equipment lines we represent and/or service. Please visit our Sales Tab for a listing.
